Automatic IBC Decanting System 6-10 M3/H Unloading Speed

Name: Automatic IBC Decanting System 610 M3H Unloading Speed
Brand: Beijing VP
Price: 1 USD

Buy cheap Automatic IBC Decanting System 6-10 M3/H Unloading Speed product

Brand Name : Beijing VP

Model Number : Customized according to demand

Standard barrel capacity : 200L barrel/IBC

Empty bucket residual amount : less than 0.5kg after rinsing 200L drum

Unloading speed : 6-10 m3/h

Full time in automatic mode : less than 6 min/drum

System pressure : 16bar

Temperature range : 40℃~130℃

Viscosity range : Up to 2,000 cps

Contact Now

Automatic IBC Decanting System 6-10 M3/H Unloading Speed

Characteristics:

VP Drum Decanting Unit is an automatic decanting system for high viscosity additives. The equipment is designed to perform quantitative decanting in drum, rinsing empty drum and empty the drum. The weighing system can be tilted and lance to track the liquid level during decanting.

Decanting and Rinsing data can be set at site. The control can be set to Automatic or Manual mode.

High efficient decanting process, zero leakage and no contamination.

Working Scope:

Standard barrel capacity	200L barrel/IBC
Empty bucket residual amount	less than 0.5kg after rinsing 200L drum
Unloading speed	6-10 m³/h
Full time in automatic mode	less than 6 min/drum
System pressure	16bar
Temperature range	40℃~130℃
Viscosity range	Up to 2,000 cps
Lance	Bottom Valve, 3 level for decanting/rinsing/close. Lance can trace liquid level automatically.
Control system	DDU can operate from the HMI and communicate with the DCS
Field display	Input parameters, real-time display of weight of rinsing tank and additives, alarm indicator, emergency stop button
Rinsing oil tank	with heating jacket and insulation
Gross weight	about 2550 kg
